Laser Direct Patterning Equipment
This equipment is a laser direct patterning equipment using IR Laser.
It can fine-pitch pattern silver paste on the PET Film, by use of laser paste and scan head.
Mobile Production Equipment
|
Model |
HDP600 / HDP710-I4H4-M30 / HDP1100-I2H2-M15 / HDP2100-I1H1-M30 |
||
|
Characteristics |
1. Ultra-precision accuracy 2. 15um L/S 3. High productivity 4. No etching process required
|
||
|
Specifications |
Machining by use of in-house optical system developed from IR Laser, and Scan Head and Stage Scan head machining area : 150x150mm ~ 300x300mm Number of heads : 1 head ~ 4Head Maximum machining area : 1050mm×700mm |
||
|
Application |
Touch panel / |
Suitable materials |
Material name : Silver Paste & ITO |
